2025 Best Industrial Water Chillers for Blow Molding Machines
The industrial water chiller is essential in the blow molding production line. It is very important for the blow molding industry to choose a suitable chiller. Here, we will introduce in detail several of the best industrial water chillers and provide a good solution for blow molding practitioners
What Is an Industrial Water Chiller？
industrial water chiller is a refrigeration system that removes heat from machinery or process fluids using a vapor-compression cycle. Its core components include:
Compressor: Circulates refrigerant (e.g., R-134a or eco-friendly alternatives).
Evaporator: Absorbs heat from water/glycol mixtures.
Condenser: Expels absorbed heat via air or water cooling.
Circulation Pump: Moves chilled fluid (5°C–25°C) to equipment like blow molding machines.
Unlike household ACs, chillers offer precision temperature control (±0.5°C), handle heavy loads (up to 1,500 kW), and withstand harsh factory environments.
Key Applications of industrial Chiller in Manufacturing
Industrial chillers are critical in sectors where temperature stability affects product quality:
PET Blow Molding: Cools molds rapidly to prevent PET bottle deformation, reduce cycle times by 30%, and ensure surface gloss.
Metalworking: Controls oil temperature in CNC machines to minimize thermal expansion.
Pharmaceuticals: Maintains bioreactor temperatures during drug synthesis.
Energy: Cools gas turbines and nuclear reactor components.
In blow molding, chillers prevent defects like warping, uneven wall thickness, and haze—saving up to 20% in material waste
How to Choose the Right Water Chiller for Blow Molding
Selecting a chiller requires matching specs to your blow molding machine’s needs:
A. Cooling Capacity & Temperature Range
Calculate heat load: For PET blow molding, budget 0.5–1 kW/ton of cooling per hour.
Standard chillers (5°C–25°C) suit most PET bottle production.
Low-temp chillers (-10°C to -45°C) are needed for high-clarity containers or fast-cycle lines.
B. Energy Efficiency
Opt for variable-speed compressors and EC fans (like CIAT’s POWERCIAT™ XE) to cut energy use by 30%.
SEER (Seasonal Energy Efficiency Ratio) should exceed 4.0.
C. Form Factor & Compatibility
Air-cooled chillers: Ideal for water-scarce areas; require good ventilation.
Water-cooled chillers: 15% more efficient but need cooling towers.
Compact modular units (e.g., TOOL TEMP TT-30/160) save floor space.
D. Smart Features
IoT-enabled monitoring (e.g., remote leak alerts).
Self-diagnostic systems to prevent downtime.
Top 5 Best Industrial Chillers in 2025 Compared
Here are 5 top best industrial chiller brands and their popular models, based on performance, efficiency, and industry adoption in 2025:
| Brand | Model | Cooling Capacity | Temperature Range | Compressor Type | Key Features | Primary Applications |
|---|---|---|---|---|---|---|
| Faygo Union | FG HE/XE | 3.45kw–1,493 kW | -20°C to +55°C | Twin-screw | SEER up to 4.7, SEPR up to 6.2; Aluminum micro-channel condenser; Variable-speed EC fans; IoT-enabled control | PET bottle production (2k~48k+ bottles/hr); Industrial process cooling |
| (Bing Ling) | BLSC Series | Customizable (5–20°C standard) | 0–4°C (glycol) or 5–20°C | Semi-hermetic twin-screw | Energy-efficient tube heat exchangers; Multi-level safety protection; PLC control with “one-touch start” | Chemical, pharmaceutical, steel, electronics, food processing 2 |
| Conair | ECO Series Outdoor | Up to 720 tons (modular) | -29°C to 52°C (ambient) | Scroll | Compact footprint; Rugged stainless steel evaporator; 7″ color touchscreen; Dual-circuit redundancy | Blow molding in harsh environments; Outdoor installations |
| Carrier | AquaEdge® 19XR/XRV | 1,055–10,548 kW | Process-specific | Centrifugal | HFC-134a refrigerant; Two-stage compressor; Hermetic motor; Low noise | Large facilities (comfort/process cooling); Heat pumps; Ice storage |
| LAUDA | Ultracool UC-ST/SP | 1.9–265 kW | -5°C to 25°C | N/A | Corrosion-resistant epoxy-coated housing; Frost protection; Pressure switches | Laser cutting/engraving; Digital printing; Injection molding |
Key Insights:
Faygo union leads in energy efficiency (SEPR 6.2) and suits mega-plants needing 24/7 operation
BLSC excels in customization for diverse industrial fluids and temperatures
Conair ECO Series thrives in extreme outdoor conditions (-29°C to 52°C) with minimal maintenance
Carrier 19XR/XRV dominates large-scale applications (e.g., 10,548 kW cooling) with centrifugal compression
LAUDA Ultracool offers precision control (±0.1°C) for sensitive processes like laser systems
Conclusion: Matching Your Needs to the Best Industrial Water Chiller
For most blow molding operations, the Faygo Union chiller offers the best balance of cost, efficiency, and reliability. Large-scale producers should prioritize Carrier for its unmatched energy savings. Whichever model you choose, ensure it includes:
±0.5°C temperature stability
Corrosion-resistant evaporators (stainless steel/copper-nickel)
3-year minimum warranty
Need Help Optimizing Your Setup? Request quotes for these top-rated chillers to boost output and slash energy bills!
